Automatic rod pulling machine

Automatic Rod Pulling Machine

An Automatic Rod Pulling Machine is specialized equipment used in finned tube production lines to automatically pull or extract rods from tubes after processes such as forming, welding, or finning. It ensures high precision, consistent operation, and smooth production workflow.

Key Features

• Fully automatic rod pulling for improved efficiency

• Precise and uniform operation to prevent tube or rod damage

• Adjustable for different rod and tube diameters

• Stable performance with minimal manual intervention

• Easy to operate and maintain

Equipment Name: Automatic Heat Pipe Extraction Machine
Equipment Application: Used for heat pipe extraction; Number of Stations: 3
Processing Method: Flat push extraction
Dimensions: 1600*1200*1700MM
Processed Product Specifications: D5, D6, D8; Processing Wall Thickness: 0.1-0.3MM; Processing Length: 150-450MM
Equipment Capacity: Approx. 3600S/800PCS
Servo Motor: HIWIN (Taiwan); Control System: Mitsubishi PLC + Weintek Touch Screen (Japan)
Power Configuration: 220V Single Phase 2.5KW
