Straightening Machine

A Straightening Machine is industrial equipment used to correct bends, warps, or deformation in tubes, rods, or pipes, ensuring they are perfectly straight before further processing. It is widely used in finned tube production, heat exchanger manufacturing, and other industrial tube fabrication lines.

Key Features

• Corrects tube or rod deformation efficiently

• Adjustable settings for different diameters and lengths

• High precision and repeatable straightening

• Stable operation with minimal damage to the material

• Easy to operate and maintain

I. Equipment Application

Used for straightening heat pipes and improving their hardness.

II. Equipment Specifications

1. External Dimensions: L 850mm * W 500mm * H 870mm

2. Power Configuration: 220V Single Phase 0.5KW

3. Processing Diameter: ￠4 – ￠10

4. Processing Length: 80mm-450mm

5. Equipment Capacity: >20K/PCS

6. Processing Type: Extrusion

7. Consumable Materials: —-

III. Equipment Operation Instructions

After powering on the equipment, turn on the power button → Adjust the dial indicator scale → Place the product in the center of the rollers for straightening → Remove the finished product → Manually collect the material → Repeat the operation cycle.

IV. Equipment Functions

1. The equipment consists of straightening rollers and a drive motor.

2. The rollers are made of ground steel rods with an accuracy of ±0.05mm.

3. The roller surface uses a high-frequency process to ensure it will not be damaged during use.

4. Size adjustment is achieved using a digital micrometer with an accuracy of ±0.05mm.

5. The product surface is free of scratches after processing.
