Six-station vacuum degassing machine

Six-Station Vacuum Degassing Machine

A Six-Station Vacuum Degassing Machine is advanced equipment designed for finned tube and heat exchanger production lines. It performs vacuum degassing at multiple stations, ensuring thorough removal of air, moisture, and gases from tubes or components. This guarantees high-quality fin bonding, welding, and overall product reliability.

Key Features

• Six working stations for efficient and continuous degassing

• High vacuum ensures complete removal of trapped gases and moisture

• Adjustable for various tube diameters and lengths

• Stable operation with minimal maintenance

• Improves downstream finning, welding, and assembly quality



Applicable Type: Commonly used for both mobile phone tubes and conventional tubes
Workstations: 6 stations
Equipment Application: For vacuum degassing of heat pipes
Dimensions: 2110*1100*2100MM
Power Configuration: 380V three-phase 7.5KW
Processing Length: 50-500MM
Equipment Capacity: Depends on product characteristics
Vacuum Pump Configuration: Coarse pump: Edwards E2M28;

Fine pump: Edwards E2M80+EH250;

Maximum fine pumping speed: 250 cubic meters/hour.

Vacuum Tubing: Taiwan Riyang
Control System: Mitsubishi PLC + Weintek Touch Screen (Japan)
Processed Product Specifications: D2, D3, D4, D5, D6, D8
